Additional information
| Weight | 6,977 kg |
|---|---|
| Reference number | 544440010, 544440020, 719001007, 550017680, 6609441, 6609442, 4454107630, 4454107230, 122760, 50397006 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.65 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.46 |
| Clevis pin | 0.49 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 / 123.28 psi |
| Port angle | 90° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| ProVia warranty | 1 year |
| Push-rod length | 9.25 in |
| Push-rod thread | Ball R8 |
| Release pressure | 79.77 psi |
| Return-spring force | 22.48 lbf |
| Stroke | 2.24 in |
| Technical specification | AM specification |
| Total lenght | 6.89 in |
| Type | 16/24 |
| Type of operation | Disc |
| Yoke | Screwed |
| GTIN | 04057877008642 |
| Size (mm x mm x mm) | 320 x 205 x 190 |
| UPC | 193134006342 |
| Weight (kg) | 6.977 |
| Weight (lb) | 15.38 |
| Temperature range | -40°F to +176°F |
| Brand | WABCO |
