Additional information
| Weight | 7,1 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.466 |
| Clamp band | Ø 167 mm |
| Clamp band position | -135° |
| Diameter | 7.24 in |
| Distance between bolts | 4.75 in |
| Length | 229 mm |
| Max. operating pressure | 152.29 / 123.28 psi |
| Port angle | Position Side port 90° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 22.48 lbf |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 12.52 in |
| Type | 16/24 |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875278498 |
| Size (mm x mm x mm) | 370 x 220 x 190 |
| UPC | 193133349280 |
| Weight (kg) | 7.1 |
| Weight (lb) | 16 |
| Stroke | 2.24 / 2.24 in |
| Brand | WABCO |
