Additional information
| Weight | 9,091 kg |
|---|---|
| Reference number | 841845630, 1518582, 01173863, 1173863, 0763056, 4788302, F255880010010, WABS4111418450, 1070323, 01173863, 01173877, 01261659, 42522657, S4111418450, S4111418450, 1416530, S4111418450 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 15.406 |
| Cooling | Air |
| Crankshaft thread | M18 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 166.75 psi |
| Mounting | Foot mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 2.95 in |
| Piston stroke | 1.42 in |
| Port thread 0 | M26 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | M10 x 1 |
| Port thread 8.2 | M22 x 1.5 |
| Swept volume (cm³) | 159 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Single Cylinder |
| GTIN | 04057875155447 |
| Size (mm x mm x mm) | 229 x 207 x 325 |
| UPC | 193133435952 |
| Weight (kg) | 9.091 |
| Weight (lb) | 20.042 |
| Type of operation | High pressure using unloader |
| Brand | WABCO |
