Additional information
| Weight | 9,474 kg |
|---|---|
| Reference number | 51541017120, 51541017124, 51541017141, 51541019141, 51541017124 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 15.0247 |
| Comments | Like variant 910. but with a cap on the pump gear: integral vickers-flange, with a 10 degree angle: oil supply (81) in base |
| Cooling | Air |
| Crankshaft thread | M18 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 123.25 psi |
| Operating speed | 3000 (1/min) |
| Piston diameter | 2.95 in |
| Piston stroke | 1.42 in |
| Port thread 0 | M26 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | M10 x 1 |
| Port thread 8.2 | Ø 0.76 in |
| Swept volume (cm³) | 159 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Single Cylinder |
| GTIN | 04057875155546 |
| Size (mm x mm x mm) | 201 x 230 x 325 |
| UPC | 193133234661 |
| Weight (kg) | 9.474 |
| Weight (lb) | 20.887 |
| Type of operation | High pressure using unloader |
| Brand | WABCO |
