Additional information
| Weight | 2,1 kg |
|---|---|
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Air Tank Diameter | Ø 3.54 in |
| Calculated Volume (dm³) | 4.991 |
| Distance between holes | 3.37±0.01 in |
| Electrical connection | No Electrical connection |
| Fluid type | Brake Fluid |
| Length | 266 ± 10 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M10 x 1.25 |
| Oil inlet | Port 14 |
| Port Thread 32 | M8 x 1 |
| Port thread 11 | M14 x 1.5 |
| Port thread 14 | M12 x 1.5 |
| Port thread 31 | NPT 1/4 |
| Ports | M12 x 1.5, M14 x 1.5 |
| ProVia warranty | 1 year |
| Push-rod thread | Ball Ø0.39 in |
| Stroke | 1.38 ± 0.12 in |
| Technical specification | AM specification |
| Temperature range | -40˚C To +80˚C |
| Variant | 3.54 in |
| Voltage | No Electrical connection |
| Wear measurement | No |
| GTIN | 04057877025052 |
| Size (mm x mm x mm) | 266 x 177 x 106 |
| UPC | 193134007400 |
| Weight (kg) | 2.1 |
| Weight (lb) | 4.63 |
| Size | 266 x 177 x 106 |
| Brand | WABCO |
