Additional information
| Weight | 2,983 kg |
|---|---|
| Reference number | 1519286, 1608ZD2A-010, 504103066, 0504103066, 504103066, E504103066, 0504103066, 5010452511, 216500060, 1519286, 5010452511, 5010245488, 5010245868, 504103066, WG9114230025/2, WG91142300252, WG97192300251 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 7.1174 |
| Comments | RVI |
| Distance between holes | 5.12 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 308 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 ( G ) |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | M12 x 1.75 |
| Stroke | 0.99 in |
| Technical specification | OE specification |
| Temperature range | -30°C to +100°C |
| Size (mm x mm x mm) | 382 x 137 x 136 |
| UPC | 193133373766 |
| Weight (kg) | 2.983 |
| Weight (lb) | 6.5764 |
| GTIN | 7895851052369 |
| Brand | WABCO |
