Additional information
| Weight | 2,515 kg |
|---|---|
| Reference number | 2Z0721257A, 13H1023250AA, 5010639015, 20812661, 20812661, 20757134, 5010639015, 2Z0721257A |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.085 |
| Distance between holes | 4.33 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 329 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 1.97 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 279 x 97 x 114 |
| UPC | 193133373650 |
| Weight (kg) | 2.515 |
| Weight (lb) | 5.545 |
| GTIN | 7895851054837 |
| Brand | WABCO |
