Additional information
| Weight | 3,222 kg |
|---|---|
| Reference number | 3329101150, 3329101151, 1506466, 1602305A70A, 7C467K626AA, S31A0E0780, 4170077000K, 216500010, 501006570, 0501006570, 19356601, 1935601, 10730817, 160400241 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 10.08 |
| Distance between holes | 5.12 in |
| Fluid type | Brake Fluid |
| Length | 409 mm |
| Max. operating pressure | 145.04 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Ports | 1-4: M14 x 1.5; 11, 21: M16 × 1.5 |
| ProVia warranty | 1 year |
| Push-rod thread | Ball Ø 12.0 mm |
| Size | 4 in |
| Stroke | 3.34 in |
| Temperature range | -40°C to +80°C |
| Wear measurement | Mechanical wear indicator |
| GTIN | 04057877002442 |
| Size (mm x mm x mm) | 420 x 160 x 150 |
| UPC | 193134004805 |
| Weight (kg) | 3.222 |
| Weight (lb) | 7.103 |
| Technical specification | AM specification |
| Brand | WABCO |
