Additional information
| Weight | 3,12 kg |
|---|---|
| Reference number | A0034319806 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | EvoBus |
| Calculated Volume (dm³) | 13.356 |
| Distance between holes | 4.65×7.17 in |
| Electrical connection | 2x Bayonet DIN 72585 A1-4.1-Sn/K1 |
| Max. operating pressure | 188.5 psi |
| Mounting | 3x Ø 9.0 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.24 / 0.20 in |
| Pedal angle | 25° |
| Port thread 11 | M22 x 1.5 JED – 388-4 |
| Port thread 12 | M16 x 1.5 JED – 388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M16 x 1.5 JED – 388-4 |
| Port thread 3 | Silencer |
| Protection class | IP 66, IP 69K |
| Stroke | 0.90 in |
| Technical specification | OE specification |
| Voltage | 9 to 32 V |
| GTIN | 04057875228288 |
| Size (mm x mm x mm) | 360 x 265 x 140 |
| UPC | 193133487715 |
| Weight (kg) | 3.12 |
| Weight (lb) | 6.8784 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
