Additional information
| Weight | 1,356 kg |
|---|---|
| Reference number | DZ95259364004 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Nissan Diesel/ UD Trucks |
| Calculated Volume (dm³) | 2.296 |
| Distance between bolts | 2.4×2.4 in |
| Electrical connection | DIN 72585-A1-4.1-Sn/K1, EXTERNAL CONTOUR DIN 72585 NECESSARY SOCKET AMP NO. 0-96-7650-1 |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M6 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 / 0.20 in |
| Output force | 4945.80 lbf |
| Port thread 11 | M22 x 1.5 JED – 388-4 |
| Port thread 12 | M16 x 1.5 JED – 388-4 |
| Port thread 21 | M22x1.5 JED – 388-4 |
| Port thread 22 | M16 x 1.5 JED – 388-4 |
| Port thread 3 | Silencer |
| Protection class | IP 66, IP 69K |
| Stroke | 0.49 in |
| Technical specification | OE specification |
| Voltage | 9 to 32 V |
| GTIN | 04057875228394 |
| Size (mm x mm x mm) | 196 x 101 x 116 |
| UPC | 193133465584 |
| Weight (kg) | 1.356 |
| Weight (lb) | 2.9895 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
