Additional information
| Weight | 1,758 kg |
|---|---|
| Reference number | 1395722, 1455027, 1315685, 1935123, 1102408500 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Paccar, Solaris |
| Calculated Volume (dm³) | 3.5721 |
| Distance between bolts | 2.4×2.4 in |
| Electrical connection | DIN 72585-A1-4.1-Sn/K1, EXTERNAL CONTOUR DIN 72585 NECESSARY SOCKET AMP NO. 0-96-7650-1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Output force | 2697.71 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 3 | Silencer 480 001 520 2 |
| Protection class | IP 56, IP 59K |
| Silencer | 480 001 520 2 |
| Stroke | 0.55 in |
| Temperature range | -40°C to +80°C |
| Thread | Voss threads |
| Type | 3 |
| Voltage | 8 to 32 V |
| GTIN | 04057875228264 |
| Size (mm x mm x mm) | 239 x 141 x 106 |
| UPC | 193133316701 |
| Weight (kg) | 1.758 |
| Weight (lb) | 3.8757 |
| Technical specification | OE specification |
| Brand | WABCO |
