Additional information
| Weight | 1,716 kg |
|---|---|
| Reference number | 593107M000, 59310 7M000, 48000 14010 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Isuzu, Hino Motors, Nissan Diesel/ UD Trucks |
| Calculated Volume (dm³) | 2.3831 |
| Distance between holes | 2.4×2.4 in |
| Electrical connection | DIN 72585-A1-4.1-Sn/K1, EXTERNAL CONTOUR DIN 72585 NECESSARY SOCKET AMP NO. 0-96-7650-1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Output force | 4945.80 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port thread 12 | M16 x 1.5 JED – 152 |
| Port thread 21 | M16x1.5 JED – 152 |
| Port thread 22 | M16 x 1.5 JED – 152 |
| Port thread 3 | Union Ø 16.0 |
| Protection class | IP 56, IP 59K |
| Stroke | 0.47 in |
| Technical specification | OE specification |
| Voltage | 9 to 32 V |
| GTIN | 04057875228271 |
| Size (mm x mm x mm) | 102 x 177 x 132 |
| UPC | 193133316718 |
| Weight (kg) | 1.716 |
| Weight (lb) | 3.7831 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
