Additional information
| Weight | 1,897 kg |
|---|---|
| Reference number | 1518130, A0034318506, 0044314705, 0034318506, A0034318506, A0044314705, 1935121 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Daimler |
| Calculated Volume (dm³) | 2.914 |
| Distance between bolts | 2.4×2.4 in |
| Electrical connection | 2x Bayonet DIN 72585 A1-4.1-Sn/K1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4 Studs M 8: 0.79 in long |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Output force | 4945.80 lbf |
| Port thread 11 | Voss – 232 NG12 |
| Port thread 12 | Voss – 232 NG12 |
| Port thread 21 | Voss 232 NG12 |
| Port thread 22 | Voss – 232 NG12 |
| Port thread 3 | Silencer 480 001 520 2 |
| Port thread 4 | Voss 232 – NG 8 |
| Protection class | IP 56, IP 59K |
| Silencer | 480 001 520 2 |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Thread | Voss threads |
| Type | 1 |
| Voltage | 9 to 32 V |
| GTIN | 7895851051843 |
| Size (mm x mm x mm) | 229 x 126 x 101 |
| UPC | 193133316305 |
| Weight (kg) | 1.897 |
| Weight (lb) | 4.1822 |
| Stroke | 0.55 in |
| Brand | WABCO |
