Additional information
| Weight | 3,503 kg |
|---|---|
| Reference number | A0044316405, A0044313705, 0044316405, A0044316405, 0044313705 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | EvoBus |
| Calculated Volume (dm³) | 11.62 |
| Distance between holes | 4.65×7.17 in |
| Electrical connection | 2x Bayonet DIN 72585 A1-4.1-Sn/K1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.0 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Pedal angle | 25° |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 3 | Union Ø 16.0 mm |
| Protection class | IP 66, IP 69K |
| Stroke | 0.94 in |
| Technical specification | OE specification |
| Voltage | 8 to 32 V |
| GTIN | 04057875228257 |
| Size (mm x mm x mm) | 334 x 245 x 142 |
| UPC | 193133316749 |
| Weight (kg) | 3.503 |
| Weight (lb) | 7.7228 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
