Brake cilinder 16/24

Description

Technical details

• Brand
  WABCO Original
• Part type
  Premium original quality
• Product category
  Device
• Bolt lengths
  1.69 in
• Bolt threads
  M16 x 1.5
• Calculated Volume (dm³)
  12.321
• Clamp band
  Ø 167 mm
• Clamp band position
  160°
• Diameter
  7.24 in
• Distance between bolts
  4.75 in
• Length
  229 mm
• Max. operating pressure
  152.29 / 123.28 psi
• Port angle
  Position Side port 90°
• Port thread 11
  M16 x 1.5
• Port thread 12
  M16 x 1.5
• Push-rod length
  0.59 in
• Push-rod thread
  Ball R8
• Release pressure
  73.97 psi
• Return-spring force
  22.48 lbf
• Stroke
  2.24 / 2.24 in
• Technical specification
  OE specification
• Temperature range
  -40°C to +80°C
• Total lenght
  12.52 in
• Type
  16/24
• Type of operation
  Disc
• Version
  Without boot
• Size (mm x mm x mm)
  360 x 185 x 185
• UPC
  193133349341
• Weight (kg)
  6.7
• Weight (lb)
  15
