Additional information
| Weight | 4,98 kg |
|---|---|
| Reference number | 44310NA202, 44310NA274, 44310NA202, 44310NA274, 44310NA07D |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.98 in |
| Calculated Volume (dm³) | 9 |
| Clamp band | 185 mm |
| Clamp band position | 0° |
| Distance between holes | 3.15×1.42 in |
| Max. operating pressure | 147.94 psi |
| Mounting | 4x Ø 10.5 mm |
| Operating pressure | 147.9 psi |
| Opposite | 423 076 041 0 |
| Output force | 1978.32 lbf |
| Output force M | 1978.32 lbf |
| Port (side) | -45° |
| Port (top) | Rc 3/8" (ISO 7-1) |
| Port threads | Rc 3/8" (ISO 7-1) |
| Return-spring force | 33.72 lbf |
| Stroke | 2.17 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.84 in |
| Type | 24 |
| Type of operation | Wedge |
| Version | Without boot |
| GTIN | 04057875162247 |
| Size (mm x mm x mm) | 250 x 200 x 180 |
| UPC | 193133422761 |
| Weight (kg) | 4.98 |
| Weight (lb) | 10.98 |
| Technical specification | OE specification |
| Brand | WABCO |
