Additional information
| Weight | 2,766 kg |
|---|---|
| Reference number | 4230441030 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.98 in |
| Calculated Volume (dm³) | 5.2 |
| Clamp band | 164 mm |
| Max. operating pressure | 116.0 psi |
| Mounting | 1 3/4" – 12 UNS – 2A |
| Operating pressure | 116.0 psi |
| Output force | 1596.14 lbf |
| Output force M | 1596.14 lbf |
| Port (top) | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Stroke | 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.46 in |
| Total lenght | 7.22 in |
| Type | 18 |
| Version | Without boot |
| GTIN | 04057875161400 |
| Size (mm x mm x mm) | 196 x 169 x 157 |
| UPC | 193133479727 |
| Weight (kg) | 2.766 |
| Weight (lb) | 6.098 |
| Type of operation | Wedge |
| Brand | WABCO |
