Additional information
| Weight | 2,85 kg |
|---|---|
| Reference number | 59120 6B001 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.98 in |
| Calculated Volume (dm³) | 5.28 |
| Clamp band | 145 mm |
| Max. operating pressure | 147.94 psi |
| Mounting | M48 x 2 |
| Operating pressure | 147.9 psi |
| Output force | 1135.29 lbf |
| Output force M | 1135.29 lbf |
| Port (top) | M16 x 1.5 JED-152 |
| Port threads | M16 x 1.5 |
| Ports | 30° |
| Return-spring force | 33.72 lbf |
| Stroke | 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 8.39 in |
| Type of operation | Wedge |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875161806 |
| Size (mm x mm x mm) | 220 x 160 x 150 |
| UPC | 193133244684 |
| Weight (kg) | 2.85 |
| Weight (lb) | 6.283 |
| Type | 12 |
| Brand | WABCO |
