Additional information
| Weight | 3,961 kg |
|---|---|
| Reference number | T 22038027 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.98 in |
| Calculated Volume (dm³) | 9.282 |
| Max. operating pressure | 147.94 psi |
| Mounting | M45 x 1.5 |
| Output force M | 1641.11 lbf |
| Port threads | M16 x 1.5 |
| Return-spring force | 33.72 lbf |
| Stroke | 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.91 in |
| Type | 20 |
| Type of operation | Wedge |
| Version | Without boot |
| GTIN | 04057875313908 |
| Size (mm x mm x mm) | 272 x 195 x 175 |
| Weight (kg) | 3.961 |
| Weight (lb) | 8.7325 |
| UPC | 193133464235 |
| Brand | WABCO |
