Additional information
| Weight | 0,45 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.59 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 10.58 |
| Clevis pin | 0.49 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Port threads | M18 x 1.5 |
| Push-rod length | 2.83 in |
| Push-rod thread | M14 x 1.5 |
| Stroke | 2.50 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.06 in |
| Type | 30 |
| Type of operation | Cam |
| Version | With Boot |
| GTIN | 04057875834595 |
| Size (mm x mm x mm) | 200 x 230 x 230 |
| UPC | 193133506515 |
| Weight (kg) | 0.45 |
| Weight (lb) | 0.9921 |
| Yoke | Screwed |
| Brand | WABCO |
