Additional information
| Weight | 2,928 kg |
|---|---|
| Reference number | 7421870990 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.832 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 1348.85 lbf |
| Output force M | 1348.85 lbf |
| Port threads | M16 x 1.5 |
| Ports | 30° |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 37.09 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.02 in |
| Type of operation | Disc |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875165668 |
| Size (mm x mm x mm) | 180 x 180 x 180 |
| UPC | 193133480761 |
| Weight (kg) | 2.928 |
| Weight (lb) | 6.4551 |
| Type | 16 |
| Brand | WABCO |
