Additional information
| Weight | 3,06 kg |
|---|---|
| Reference number | 81511016373, 81511016375, 81511016394, 81511016395, 81511016407, 81511016407 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.776 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Opposite | 423 104 700 0 |
| Output force | 1416.30 lbf |
| Output force M | 1416.30 lbf |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.02 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 44.96 lbf |
| Stroke | 2.87 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.02 in |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875162674 |
| Size (mm x mm x mm) | 190 x 190 x 160 |
| UPC | 193133480129 |
| Weight (kg) | 3.06 |
| Weight (lb) | 6.7461 |
| Type | 16 |
| Brand | WABCO |
