Additional information
| Weight | 2,94 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 3.4353 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 1483.74 lbf |
| Output force 1 | 1618.62 lbf |
| Output force 2 | 1809.71 lbf |
| Output force M | 1483.74 lbf |
| Port threads | M16 x 1.5 |
| Ports | 30° |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Total lenght | 4.06 in |
| Type | 16 |
| Type of operation | Disc |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875165521 |
| Size (mm x mm x mm) | 168 x 144 x 142 |
| UPC | 193133436454 |
| Weight (kg) | 2.94 |
| Weight (lb) | 6.4816 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
