Additional information
| Weight | 3,59 kg |
|---|---|
| Reference number | 20780789 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 9.7954 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2045.76 lbf |
| Output force M | 2045.76 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 49.46 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.80 in |
| Type | 24 |
| Version | Without boot |
| GTIN | 04057875166245 |
| Size (mm x mm x mm) | 268 x 170 x 215 |
| UPC | 193133001829 |
| Weight (kg) | 3.59 |
| Weight (lb) | 7.9146 |
| Type of operation | Disc |
| Brand | WABCO |
