Additional information
| Weight | 3,58 kg |
|---|---|
| Reference number | 1791410, 1373682, 179141, 1932642 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 4.5744 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2068.24 lbf |
| Output force M | 2068.24 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 42.71 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.76 in |
| Type | 24 |
| Version | Without boot |
| GTIN | 04057875166320 |
| Size (mm x mm x mm) | 187 x 151 x 162 |
| UPC | 193133249993 |
| Weight (kg) | 3.58 |
| Weight (lb) | 7.8925 |
| Type of operation | Disc |
| Brand | WABCO |
