Additional information
| Weight | 3,6 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.65 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 8.1285 |
| Clamp band | 185 mm |
| Clamp band position | 0° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Port (side) | M22 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 20° |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.72 in |
| Type | 24 |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875166634 |
| Size (mm x mm x mm) | 224 x 162 x 224 |
| UPC | 193133436492 |
| Weight (kg) | 3.6 |
| Weight (lb) | 7.9366 |
| Technical specification | OE specification |
| Brand | WABCO |
