Additional information
| Weight | 3,72 kg |
|---|---|
| Reference number | 70369119 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.4519 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 1910.88 lbf |
| Output force M | 1910.88 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 47.21 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.76 in |
| Type | 24 |
| Version | Without boot |
| GTIN | 04057875167068 |
| Size (mm x mm x mm) | 206 x 174 x 180 |
| UPC | 193133480914 |
| Weight (kg) | 3.72 |
| Weight (lb) | 8.2012 |
| Type of operation | Disc |
| Brand | WABCO |
