Additional information
| Weight | 4,477 kg |
|---|---|
| Reference number | 1516161, 1948382 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.7084 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 psi |
| Output force | 2585.30 lbf |
| Output force M | 2585.30 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 51.71 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.69 in |
| Type | 30 |
| Version | Without boot |
| GTIN | 04057875167334 |
| Size (mm x mm x mm) | 206 x 195 x 167 |
| UPC | 193133250715 |
| Weight (kg) | 4.477 |
| Weight (lb) | 9.8701 |
| Type of operation | Disc |
| Brand | WABCO |
