Additional information
| Weight | 4,402 kg |
|---|---|
| Reference number | 1817747, 1791419, 1609333 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.3628 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Opposite | 423 509 024 0 |
| Output force | 2472.90 lbf |
| Output force M | 2472.90 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 52.83 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.24 in |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875167457 |
| Size (mm x mm x mm) | 209 x 177 x 172 |
| UPC | 193133480983 |
| Weight (kg) | 4.402 |
| Weight (lb) | 9.7047 |
| Type | 27 |
| Brand | WABCO |
