Additional information
| Weight | 2,94 kg |
|---|---|
| Reference number | UN24070060, 1505245, 1505245 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 3.469 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Opposite | 423 503 010 0 |
| Output force | 966.68 lbf |
| Output force M | 966.68 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 33.72 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.06 in |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875165378 |
| Size (mm x mm x mm) | 165 x 145 x 145 |
| UPC | 193133249337 |
| Weight (kg) | 2.94 |
| Weight (lb) | 6.4816 |
| Type | 12 |
| Brand | WABCO |
