Additional information
| Weight | 3,33 kg |
|---|---|
| Reference number | 500345267 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.1442 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 1798.47 lbf |
| Output force M | 1798.47 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Return-spring force | 49.46 lbf |
| Stroke | 2.36 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.02 in |
| Type | 22 |
| Type of operation | Cam |
| Yoke | Screwed |
| GTIN | 04057875165163 |
| Size (mm x mm x mm) | 210 x 210 x 162 |
| UPC | 193133248965 |
| Weight (kg) | 3.33 |
| Weight (lb) | 7.3414 |
| Version | Without boot |
| Brand | WABCO |
