Additional information
| Weight | 4,326 kg |
|---|---|
| Reference number | 81511016386, 81511016387, 81511016387 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.354 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Opposite | 423 109 700 0 |
| Output force | 2900.04 lbf |
| Output force M | 2900.04 lbf |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.02 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 44.96 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.65 in |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875165095 |
| Size (mm x mm x mm) | 222 x 182 x 182 |
| UPC | 193133480532 |
| Weight (kg) | 4.326 |
| Weight (lb) | 9.5372 |
| Type | 27 |
| Brand | WABCO |
