Additional information
| Weight | 3,445 kg |
|---|---|
| Reference number | 7052475, A0074201324, 1015383, 0074201324, A0074201324, 1932635 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.8 |
| Clamp band | 186 mm |
| Clamp band position | 20° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 1798.47 lbf |
| Output force M | 1798.47 lbf |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 0° |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Stroke | 2.44 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.02 in |
| Type | 22 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057875165101 |
| Size (mm x mm x mm) | 170 x 200 x 200 |
| UPC | 193133248934 |
| Weight (kg) | 3.445 |
| Weight (lb) | 7.595 |
| Return-spring force | 49.46 lbf |
| Brand | WABCO |
