Additional information
| Weight | 2,86 kg |
|---|---|
| Reference number | 445332026, 1505244, HB100202, 13C3505412AA, 1505244, 1932638 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 3.9239 |
| Clamp band | 166 mm |
| Clamp band position | 20° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 1461.26 lbf |
| Output force M | 1461.26 lbf |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 0° |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.17 in |
| Type | 14 |
| Version | Without boot |
| GTIN | 04057875165224 |
| Size (mm x mm x mm) | 183 x 151 x 142 |
| UPC | 193133249085 |
| Weight (kg) | 2.86 |
| Weight (lb) | 6.3052 |
| Return-spring force | 49.46 lbf |
| Brand | WABCO |
