Additional information
| Weight | 3,15 kg |
|---|---|
| Reference number | A6884201218, 6884201218 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 4.646 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 1351.10 lbf |
| Output force 1 | 1566.92 lbf |
| Output force 2 | 1584.90 lbf |
| Output force M | 1351.10 lbf |
| Port threads | M22 x 1.5 |
| Ports | 30° |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Return-spring force | 33.72 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Total lenght | 4.09 in |
| Type | 16 |
| Type of operation | Disc |
| Version | Without boot |
| Yoke | Without |
| GTIN | 7895851047600 |
| Size (mm x mm x mm) | 147.00 x 169.00 x 187.00 |
| UPC | 193133249146 |
| Weight (kg) | 3.15 |
| Weight (lb) | 6.945 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
