Additional information
| Weight | 4,1 kg |
|---|---|
| Reference number | 81.51101-6425, 81511016425, 81511016427, 81.51101-6491, 81511016491 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.67 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.384 |
| Clamp band | 189 mm |
| Clamp band position | 167° |
| Cylinder length | 118 |
| Distance between bolts | 4.75 in |
| Norm | TÜV certificate |
| Port (side) | M22 x 1.5 |
| Port (top) | M22 x 1.5 |
| Port angle | 90° |
| Port: working pressure [p emax.] | 10.2 |
| ProVia warranty | 1 year |
| Push-rod length | 1.02 in |
| Stroke | 3 in |
| Technical specification | AM specification |
| Type | 24 |
| GTIN | 04057877018344 |
| Size (mm x mm x mm) | 210 x 190 x 160 |
| UPC | 193134006410 |
| Weight (kg) | 4.1 |
| Weight (lb) | 9.039 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
