Additional information
| Weight | 3,9 kg |
|---|---|
| Reference number | AB4235061430, 1517956, 7054433, A0074201424, 3519015DA1S, 006993, 6993, 500590336, 337902, 10218884, 4235060010, 0074201424, A0074201424, 74201424, 1664253, 17157, 1517956, 3454106960, 1932640, 1542896, WA4235060010, 70330019, 3177339 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.67 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.182 |
| Clamp band | 189 mm |
| Clamp band position | 20° |
| Cylinder length | 108 |
| Distance between bolts | 4.75 in |
| Norm | TÜV certificate |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 0° |
| Port: working pressure [p emax.] | 10.2 |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Stroke | 2.50 in |
| Technical specification | AM specification |
| Type | 24 |
| GTIN | 04057877018375 |
| Size (mm x mm x mm) | 210 x 190 x 180 |
| UPC | 193134006373 |
| Weight (kg) | 3.9 |
| Weight (lb) | 8.598 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
