Additional information
| Weight | 3,4 kg |
|---|---|
| Reference number | 445332068, 1505241, A0064205224, 13844, 007912, 7912, AJV4526, 169345, 4231047100, 2001036, 2001001, 58128660, 5812866, 5058128660, 505812866, 334652, 4110711, 0064205224, A0064205224, 64205224, 1815504, 14338, 1505241, 4454106560, 4454108160, 3454106560, 3454108160, 1932621, 50397001, WA4231047100 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.67 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.6 |
| Clamp band | 172 mm |
| Clamp band position | 20° |
| Cylinder length | 102 |
| Distance between bolts | 4.75 in |
| Norm | TÜV certificate |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 0° |
| Port: working pressure [p emax.] | 10.2 |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Stroke | 2.24 in |
| Technical specification | AM specification |
| Type | 16 |
| GTIN | 04057877018412 |
| Size (mm x mm x mm) | 200 x 175 x 160 |
| UPC | 193134006434 |
| Weight (kg) | 3.4 |
| Weight (lb) | 7.496 |
| Temperature range | -40°F to +176°F |
| Brand | WABCO |
