Additional information
| Weight | 3,108 kg |
|---|---|
| Reference number | A0044201624, 0044201624, A0044201624 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.1187 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2203.13 lbf |
| Output force M | 2203.13 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.13 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.53 in |
| Type | 24 |
| Version | With Boot |
| Yoke | Ø14 |
| GTIN | 04057875163541 |
| Size (mm x mm x mm) | 207 x 167 x 177 |
| UPC | 193133246305 |
| Weight (kg) | 3.108 |
| Weight (lb) | 6.852 |
| Type of operation | Cam |
| Brand | WABCO |
