Additional information
| Weight | 3,824 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 11.4616 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2068.24 lbf |
| Output force M | 2068.24 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 7.48 in |
| Push-rod thread | M16 x 1.5 |
| Return-spring force | 22.48 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 4.21 in |
| Type | 24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Ø14 |
| GTIN | 04057875163619 |
| Size (mm x mm x mm) | 328 x 182 x 192 |
| UPC | 193133246886 |
| Weight (kg) | 3.824 |
| Weight (lb) | 8.4305 |
| Total lenght | 5.00 in |
| Brand | WABCO |
