Additional information
| Weight | 3,592 kg |
|---|---|
| Reference number | AB4231062020, 1331430, 118473, 331430, 70306611 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.998 |
| Clamp band | 186 mm |
| Clamp band position | 90° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 1843.43 lbf |
| Output force M | 1843.43 lbf |
| Port (side) | M16 x 1.5 JED-464-0 |
| Port (top) | M16 x 1.5 JED-464-0 |
| Port angle | 0° |
| Port threads | M16 x 1.5 |
| Push-rod length | 4.02 in |
| Push-rod thread | M16 x 1.5 |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 3.94 in |
| Type | 24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875163732 |
| Size (mm x mm x mm) | 191 x 177 x 207 |
| UPC | 193133247166 |
| Weight (kg) | 3.592 |
| Weight (lb) | 7.919 |
| Return-spring force | 44.96 lbf |
| Brand | WABCO |
