Additional information
| Weight | 4,313 kg |
|---|---|
| Reference number | A0084208224, 0084208224 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.6785 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 562.02 lbf |
| Output force 1 | 2708.95 lbf |
| Output force 2 | 3585.70 lbf |
| Output force M | 562.02 lbf |
| Port threads | M22 x 1.5 |
| Ports | 15° |
| Push-rod length | 2.13 in |
| Push-rod thread | M12 x 1.5 |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.57 in |
| Type | 30 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | With |
| GTIN | 04057875164289 |
| Size (mm x mm x mm) | 209 x 209 x 130 |
| UPC | 193133248033 |
| Weight (kg) | 4.313 |
| Weight (lb) | 9.5085 |
| Technical specification | OE specification |
| Brand | WABCO |
