Additional information
| Weight | 4,095 kg |
|---|---|
| Reference number | 0656045, 656045, 0691603 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 13.3608 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2922.52 lbf |
| Output force M | 2922.52 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 6.38 in |
| Return-spring force | 22.48 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.00 in |
| Type | 30 |
| Version | Without boot |
| Yoke | Ø14 |
| GTIN | 7895851081758 |
| Size (mm x mm x mm) | 293 x 200 x 228 |
| UPC | 193133248170 |
| Weight (kg) | 4.095 |
| Weight (lb) | 9.0279 |
| Type of operation | Cam |
| Brand | WABCO |
