Additional information
| Weight | 4,45 kg |
|---|---|
| Reference number | 605107100, 84012958, 0834484, 705707, 834484, 8283572000, 8283850000, 89199797614, 0943, 006674, 006763, 9628S4231079000, ASX0014021, M02027203, A3309600VAS, 201241, 4231079000, AZ52824, WZ2480155, 2001009, S423-107-900-0, 945152, 50945152, 82830500000, 175204, 79545, 1109377, 4110441, 834484, BBU5933, 502966208, 502920501, 4231079000, 5680047, 0005680047, 0004208024, S4231079000, 07010030, 305052, 0305052, 0834484, S423-107-900-0, 5000815361, 5021170052, 4454103900, 1738481, 1010155, 051017, 82830500000, 51017, 1232785, 3553, 96924700, 21151105030, T42-106, WA4231079000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.17 |
| Clamp band | 209 mm |
| Clamp band position | -45° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 123.28 psi |
| Operating pressure | 123.3 psi |
| Output force | 2922.52 lbf |
| Output force M | 2922.52 lbf |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 180° |
| Port threads | M16 x 1.5 |
| Push-rod length | 7.32 in |
| Push-rod thread | M16 x 1.5 |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 7.32 in |
| Total lenght | 5.04 in |
| Type | 30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875164579 |
| Size (mm x mm x mm) | 297 x 197 x 208 |
| UPC | 193133457107 |
| Weight (kg) | 4.45 |
| Weight (lb) | 9.8106 |
| Return-spring force | 22.48 lbf |
| Brand | WABCO |
