Additional information
| Weight | 4,278 kg |
|---|---|
| Reference number | 7051527, A0024202724, 163792, 0024202724, A0024202724, 2090004 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.32 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 11.52 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2922.52 lbf |
| Output force M | 2922.52 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.13 in |
| Push-rod thread | M14 x 1.5 |
| Return-spring force | 61.60 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.57 in |
| Type | 30 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Ø14 |
| GTIN | 04057875164562 |
| Size (mm x mm x mm) | 200 x 240 x 240 |
| UPC | 193133246992 |
| Weight (kg) | 4.278 |
| Weight (lb) | 9.431 |
| Total lenght | 4.92 in |
| Brand | WABCO |
