Additional information
| Weight | 3,999 kg |
|---|---|
| Reference number | A0074208824, 0064201424, 0074208824, A0074208824, A0064201424 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.48 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.2046 |
| Clamp band | 209 mm |
| Clamp band position | 0° |
| Clevis pins | 14 H11 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 2248.09 lbf |
| Output force M | 2248.09 lbf |
| Port (side) | M22 x 1.5 JED-388 |
| Port (top) | M12 x 1.5 |
| Port angle | 0° |
| Port threads | M22 x 1.5 |
| Push-rod length | 2.13 in |
| Stroke | 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.57 in |
| Type | 27 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Welded |
| GTIN | 04057875164753 |
| Size (mm x mm x mm) | 212 x 177 x 192 |
| UPC | 193133248415 |
| Weight (kg) | 3.999 |
| Weight (lb) | 8.8163 |
| Return-spring force | 56.20 lbf |
| Brand | WABCO |
