Additional information
| Weight | 4,352 kg |
|---|---|
| Reference number | 81511016481, 81511016481 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.48 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.7702 |
| Clamp band | 198 mm |
| Clamp band position | 0° |
| Clevis pins | 14 H11 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 2427.94 lbf |
| Output force M | 2427.94 lbf |
| Port (top) | M16 x 1.5 JED-152 |
| Push-rod length | 1.57 in |
| Push-rod thread | M14 x 1.5 |
| Return-spring force | 44.96 lbf |
| Stroke | 2.95 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.65 in |
| Type | 27 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Screwed |
| GTIN | 7895851069435 |
| Size (mm x mm x mm) | 183 x 220 x 193 |
| UPC | 193133248828 |
| Weight (kg) | 4.352 |
| Weight (lb) | 9.5945 |
| Technical specification | OE specification |
| Brand | WABCO |
