Additional information
| Weight | 3,54 kg |
|---|---|
| Reference number | 1302944, 1518641, 41302944 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.6 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2203.13 lbf |
| Output force M | 2203.13 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 9.06 in |
| Return-spring force | 22.48 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.00 in |
| Type | 24 |
| Version | Without boot |
| Yoke | Ø14 |
| GTIN | 04057875163534 |
| Size (mm x mm x mm) | 200 x 200 x 390 |
| UPC | 193133480273 |
| Weight (kg) | 3.54 |
| Weight (lb) | 7.8044 |
| Type of operation | Cam |
| Brand | WABCO |
