Additional information
| Weight | 3,31 kg |
|---|---|
| Reference number | 1629035, 20927144, 1605734 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.652 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 1573.66 lbf |
| Output force M | 1573.66 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.28 in |
| Push-rod thread | M16 x 1.5 |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.97 in |
| Total lenght | 4.84 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057875162759 |
| Size (mm x mm x mm) | 170 x 190 x 175 |
| UPC | 193133245780 |
| Weight (kg) | 3.31 |
| Weight (lb) | 7.297 |
| Type | 20 |
| Brand | WABCO |
