Additional information
| Weight | 4,127 kg |
|---|---|
| Reference number | A0074209024, 0064206024, 0074209024, A0074209024, A0064206024 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.48 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.247 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2360.49 lbf |
| Output force M | 2360.49 lbf |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.46 in |
| Push-rod thread | M14 x 1.5 |
| Return-spring force | 56.20 lbf |
| Stroke | 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.46 in |
| Type | 27 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Screwed |
| GTIN | 04057875164906 |
| Size (mm x mm x mm) | 165 x 263 x 167 |
| UPC | 193133248491 |
| Weight (kg) | 4.127 |
| Weight (lb) | 9.0985 |
| Total lenght | 4.57 in |
| Brand | WABCO |
